ET 438A MATLAB Programming Tutorial  Part 5  DC Motor Transfer Function

Demonstration Summary

This demonstration shows how to create transfer functions and plot their responses using MATLAB.  This video shows how to use the MatLAB instructions from the command line to create the transfer function from the computed coefficients, generate and format the Bode plot, and produce the step response for the same transfer function.  This is used to complete the current-fed dc motor homework assignment.

Department of Technology

The following presentation requires an HTML 5 compatible browser.


If you have trouble viewing this presentation contact the course instructor by email. To download the video file click here.
